Bearings, Shafts, & Spacers

The Vortex Shaft - MAXSwerve Integrated Key is compatible with the REV ION System and gives users the ability to drive a MAXSwerve Module without the need for the MAXSwerve Key. This eliminates a potential point of failure in the MAXSwerve since the key...

The Vortex Shaft - 20DP Gear - 7T is compatible with the REV ION System and offers users the unique ability to achieve substantial gear reductions directly from the motor. This gear features a 7T 20DP design that is typically too small for an 8mm keyed...

The Vortex Shaft - Falcon Compatible Spline is compatible with the REV ION System and gives users the ability to drive components that have a falcon spline bore. *Falcon is not a REV trademark. Featuring a 1/2in hex section that drives the shaft and a...

The 8mm Vortex Shaft, compatible with the REV ION System, empowers you to utilize the NEO Vortex Brushless Motor with any 8mm keyed shaft component. This interchangeability also means that the NEO Vortex matches the output of a NEO Brushless Motor V1.1,...

The Vortex MAXPlanetary Input Kit is compatible with the REV ION System and gives users the ability to mount a MAXPlanetary Gearbox directly to your NEO Vortex Brushless Motor and SPARK Flex Motor Controller. Working seamlessly with the MAXPlanetary...

The MAXSpline Shaft is compatible with the REV ION System. The shaft is an extruded aluminum MAXSpline that provides a high strength alternative to 1/2in hex shaft that can interface with any REV ION System components with a MAXSpline bore. The...

Dead Axle Tube is compatible with the REV ION System and can be used with 3/4in Needle Bearing Carrier (REV-21-2385) and MAXSpline Shaft (REV-21-2520) as the dead axle in a dead axle roller. Can also be used with custom rollers and as...

The 1in Pivot Joint is compatible with the REV ION System. Create a pivot joint at the end of a piece of MAXTube - 1x1 with Grid Structure. Specifications Material: POM (Acetal/Delrin) Documentation ION Build System Guide Introduction to...

#10-32 Standoffs are compatible with the REV ION System and provide spacing for mounting key items on your robot. These standoffs are tapped on each end for a #10-32 thread and have a 3/8in flat to flat dimension, similar to a #10-32 nut...

1/2in Rounded Hex Shafts are compatible with the REV ION System and are a ready-to-use length of hex shaft that have been cut to length and have the ends tapped. The ends are tapped #10-32 in order to accept a screw and washer or shaft collar. The 1/2in...

#10 Spacers are compatible with the REV ION System and are an accurate way to space structural components like plates, brackets, or tubes apart on #10 screws. Can also be used to to space motion components like gearboxes away from their mounting...

MAXSpline Spacers are compatible with the REV ION System and can be used on the shaft as a spacer; they also work as spacers between wheels and sprockets, etc. The MAXSpline Spacer with MAX Pattern features a 2in bolt circle pattern.  Specifications...

1/2in Hex Shaft Spacers are compatible with the REV ION System and can be used on the shaft as a spacer; they also work as spacers between wheels and sprockets, etc. Specifications Material: POM (Acetal/Delrin) OD: 0.72in Weights & Dimensions: ...

MAXSpline Spacers are compatible with the REV ION System and can be used on the shaft as a spacer; they also work as spacers between wheels and sprockets, etc. Specifications Material: POM (Acetal/Delrin) OD: 1.50in Weights &...

Commonly included with our gearboxes and pinion options, the 8mm Keyed Shaft Retaining Hardware Pack is compatible with the REV ION System and includes the hardware needed to retain 2mm keyed elements to 8mm OD shafts without the bulk of alternative...

The MAXLift Bearing Blocks are integral components of the MAXLift system, providing teams with a robust and space-efficient solution for building high-performance elevator assemblies. With the main blocks being designed around billet aluminum...

Bearings 1/2in Hex Bearing - Flanged - 1.125in OD - 4 Pack (REV-21-1915-PK4) This flanged bearing provides a reliable way to locate and support a 1/2in hex shaft or 1/2in rounded hex shaft while it rotates. The flange ensures secure installation in...

#10-32 Shaft End Screw V1 and V2 are compatible with the REV ION System and are used to retain parts on any ION hex shaft instead of shaft collars. 1/2in Rounded Hex Shafts in various lengths are available and come tapped with #10-32 holes. The...

The Vortex Shaft - 15T Spline, compatible with the REV ION System and gives users the ability to drive inputs that have a 8mm diameter involute 15T spline. Compatible with SplineXS shaft components. Featuring a 1/2in hex section that drives the shaft and...

The 1/2in Hex Bore Shaft Collars are used to prevent gears, sprockets, wheels, and other parts from sliding out of place on a 1/2in hex shaft. All REV 1/2in Hex Bore Shaft Collars feature a boss, or bump out, to contact the inner race of bearings that...
