MiniBot Hardware Kit

SKU:
REV-45-1171
$125.00

Assembly Instructions

Download the MiniBot Assembly Guide.

For an animated assembly video please click on the Product Videos tab above!

The videos are also found on our REV MiniBot Playlist.

Kit Contents:

Motors:

QTY 2 - Core Hex Motor w/cables (REV-41-1300)

Wheels:

QTY 4 - Traction Wheel, 90mm (REV-41-1354)

Structure:

QTY 2 - Extrusion, 225mm, 90-90 Degree (REV-41-1431)
QTY 2 - Battery Holder Plate (REV-41-1166)

Gears:

QTY 4 - Gear, 72T (REV-41-1336)
QTY 4 - Gear, 90T (2 packs of REV-41-1337)

Motion:

QTY 8 - Bracket, Motion (REV-41-1303)
QTY 8 - Bracket, Bearing Pillow Block (REV-41-1317)
QTY 12 - Bearing, Through Bore Short (REV-41-1326)
QTY 12 - Bearing, Through Bore Long (REV-41-1329)
QTY 8 - Shaft, 5mm Hex, 75mm (2 packs of REV-41-1347)
QTY 16 - Spacer, 3mm (REV-41-1324)
QTY 28 - Spacer, 1.5mm (1 pack of REV-41-1325)
QTY 20 - Shaft Collars (2 packs of REV-41-1327)

Tools:

QTY 1 - Nut Driver, 5.5mm (REV-41-1119)
QTY 1 - Allen Wrench, 1.5mm (REV-41-1376)

Fasteners and Hardware:

QTY 100 - Screw, Hex Cap, M3, 8mm (REV-41-1359)
QTY 4 - Screw, Hex Cap, M3, 16mm (Sub-pack of REV-41-1360)
QTY 100 - Nut, Locking, M3 (REV-41-1361)
